Automatic busbar bending machine for busduct copper aluminum joint cutting

Name: Automatic busbar bending machine for busduct copper aluminum joint cutting
Brand: Kiande
Price: 1 USD

China Automatic busbar bending machine for busduct copper aluminum joint cutting wholesale

Brand Name : Kiande

Model Number : KD-DTYTJ-C/A-4.5(6)

Certification : ISO9001

Place of Origin : China

MOQ : 1 set

Price : customized

Payment Terms : T/T, L/C

Supply Ability : 10set/ month

Delivery Time : 30 working days

Packaging Details : plywood case

Name : busbar bending machine

Stroke of X Axis : 1200mm

Speed of X Axis : 500mm/s

Punching Stroke : 50mm

Distance Accuracy of Two Holes : ±0.1mm

Max. Hydraulic Force : 31.5MPa

Contact Now

Automatic busbar bending machine for busduct copper aluminum joint cutting

The automatic busbar conductor multifunctional processing machine is a machine with unmanned operation. Operator only needs to set the related data on the touch screen such as current ratings,quantity, hole distance, raw material length and etc. and strip conductors will be processed automatically. This will save labor cost and win stable and good quality. As connection bar type is different in the joint, machine can be customized according to the requirement to proceed hole punching, counter bore, cutting and etc..

Technical parameters

Force(KN)	Punch		300
	Stretch		300
	Shear		300
Stroke of X Axis			1200mm
Max. Speed of X Axis			500mm/s
PunchingStroke			50mm
Distance Accuracy of Two Holes			±0.1mm
Conductor(Aluminum, Copper)		Length	6000mm
		Width	100mm~140mm
		Thickness	2mm~4.5mm
Max. Hydraulic Force			31.5MPa
Power			380~415VAC kW

Automatic busbar bending machine for busduct copper aluminum joint cutting

Automatic busbar bending machine for busduct copper aluminum joint cutting Images
